Worm Drive - Wheel Rotating Around Worm

The wheel rotates around the worm.
The red hand proves that the wheel rotates around its axle.
Completing 1 revolution around the worm axle, the wheel makes Z1/Z2 revolution around its axle.
Z1: number of threads of the worm.
Z2: tooth number of the wheel.
