Face Gear

Mechanism for converting two-way to one-way rotation.
The blue input shaft may change rotation direction but the rotation direction of the yellow output gear keeps unchanged.
The pink shaft moves longitudinally when the input reverses because of axial component of gear force in the blue gear drive.
The mechanism should be used only for low speed case because of gear collision.
