Festooning Cable System

Pink lever and green lever on each car are connected together via gear sectors.
Pink lever and green lever on adjacent cars are connected together by a spherical joint.
So the cars can move along curved runway and distances between two adjacent cars are always equal.
The power cable (in zigzag shape) is attached to the small rings on red, pink and green levers.
