Spatial Slider Crank Mechanism

Input: orange crank shaft rotating continuously.
Output: green slider reciprocating linearly.
Moving direction of the slider is parallel to rotary axis of the crank shaft.
It can be also used for converting linear reciprocating motion into continuous rotation
