Straight Line Drawing Mechanism

AB: pink crank length.
Center distance of the bearings AC = 1.4 AB
BE = 0.2 AB
Point E traces green line, a portion of which is approximately straight.
The straight portion corresponds rotary angle of +/- 12 deg. of the crank.
Distance from A to it: 0.57 AB.
