Toggle Linkage

Mechanism for a stone crusher.
It has two toggle linkages in series to obtain a high mechanical advantage. When green link reaches the top of its stroke, it comes into toggle with the pink crank. At the same time two blue links come into toggle. This multiplication results in a very large crushing force of the orange jaw.
