Worm and Face Gear Drive

Worm: 2 starts.
Wheel: 10 teeth.
Transmission ratio: 5.
Rotary axes of the worm and the wheel are intersecting at an angle of 90 deg. It works like a bevel gear drive but its load capacity is much higher.
Here tooth profile of the wheel was created in an approximate way, so the motion is not smooth.
